Truck Mounted Cranes

Truck Mounted Cranes

One of the things you need to ensure when getting truck mounted cranes is choosing the best in the market. Our catalog is made of the best quality cranes for both new and returning clients. We are committed to delivering quality, whether you choose to go with a knuckle boom crane or a telescopic boom option.


The list below contains some of our top BOB-LIFT truck mounted cranes.  They get assembled on whatever truck you need them on as long as they are compatible. Our cranes have different weights as well and we will help you figure out what works best.


  • 6.3 Ton Telescopic Boom Truck Mounted Crane
    6.3 Ton Telescopic Boom Truck Mounted Crane
    The 6.3 Ton Telescopic Boom Truck Mounted Crane has a 6.3 ton maximum lifting capacity with a 16 ton.m maximum lifting moment. It requires 900mm of installation space, weighs 2150 kgs, and has a 360-degree continuous rotation angle.

    Inquire
  • video 6.3 Ton Knuckle Boom Truck Mounted Crane
    6.3 Ton Knuckle Boom Truck Mounted Crane
    The 6.3 Ton Knuckle Boom Truck Mounted Crane has a 6.3 ton maximum lifting capacity and a 13 ton.m maximum lifting moment. It requires a 1050mm installation space and has a 400-degree rotation angle.

    Inquire
  • 8 Ton Telescopic Boom Truck Mounted Crane
    8 Ton Telescopic Boom Truck Mounted Crane
    This crane has an 8-tonne max lifting capacity and a 20-TON.m maximum lifting moment. It requires a 1200mm installation space, and has a 360, continuous rotation angle. The 8-ton telescopic boom truck mounted crane is perfect for demanding jobs requiring durable machines.

    Inquire
  • video 5 Ton Knuckle Boom Truck Mounted Crane
    5 Ton Knuckle Boom Truck Mounted Crane
    The 5-ton Knuckle Boom Truck Mounted Crane has a 5-ton maximum lifting capacity and a 10.5-ton maximum lifting moment. It has a 35L/min hydraulic system flow, a 28 Mpa hydraulic system pressure, and a 1050mm installation space. The crane weighs 1850kgs and has a 400-degree rotation angle.

    Inquire
  • 10 Ton Telescopic Boom Truck Mounted Crane
    10 Ton Telescopic Boom Truck Mounted Crane
    The beneficial characteristics of the 10 Ton Crane are a 25 Ton.m maximum lifting moment,10-ton maximum lifting capacity, 30 KW recommended power, 25 MPa hydraulic system pressure and 63 L/min hydraulic system flow. You require a 1200mm space for set up and it comes with a 360-degree continuous rotation angle.
    Inquire
  • 8 Ton Knuckle Boom Truck Mounted Crane
    8 Ton Knuckle Boom Truck Mounted Crane
    The crane has an 8-tone maximum lifting capacity and a 16 ton.m maximum lifting moment. It also has a 390-degree rotation angle making it quite efficient and requires 1150mm of installation space to operate.
    Inquire
  • 12 Ton Telescopic Boom Truck Mounted Crane
    12 Ton Telescopic Boom Truck Mounted Crane
    The 12-ton maximum lifting capacity, 30 Ton.m maximum lifting moment, 30 KW recommended power, 360-degree continuous rotation angle, and63 L/m hydraulic system flow are some of the features you can look forward to with the 12 Ton Telescopic Boom Truck Mounted Crane.
    Inquire
  • video 10 Ton Knuckle Boom Truck Mounted Crane
    10 Ton Knuckle Boom Truck Mounted Crane
    The 10 ton knuckle boom truck mounted crane has a 10 ton maximum lifting capacity and a 20 ton.m maximum lifting moment. It has a 25KW recommended power and a 40 L/min hydraulic system flow. The crane requires a 1200mm installation space and has a 380-degree rotation angle.

    Inquire
Xuzhou BOB-LIFT Construction Machinery Co., Ltd. is a high-tech enterprise specializing in the design, development, manufacture and sales of truck-mounted cranes. With a factory area of over 37,000 square meters, the company's main products include SQ08-SQ55 series of folding and telescopic boom truck-mounted cranes and related variants such as truck mounted crane, marine crane, pickup crane.
